Description
This AirPro IEFB 330 is a rugged industrial fan purpose-built for material handling applications, where durability and performance matter in moving particulate-laden airstreams. Constructed with a carbon steel housing and wheel, this fan is designed to withstand challenging environments involving dust, bulk materials, and abrasive particulates.
Featuring a 33-inch wheel in an Arrangement 4V configuration with CW rotation, the IEFB 330 is driven by a premium-efficiency 10 HP, 1200 RPM TEFC motor (NEMA 256T). Rated for 150 °F operation with a maximum thermal change rate of 15 °F/min, this fan provides consistent operation in demanding process conditions.
Key design features include:
-
Carbon steel airstream and wheel for rugged material handling applications
-
Flanged & drilled inlet/outlet connections for secure installation
-
Bolted access door and drain with plug for convenience in maintenance and cleaning
-
Ceramic felt shaft seal to reduce dust leakage and improve reliability
-
Industrial enamel coating for corrosion and wear resistance
-
Estimated ship weight: 700 lb (base fan only)
The AirPro IEFB 330 is a durable material handling fan, ideal for moving bulk particulates, dust, and abrasive airstreams in rugged industrial processes.
Included Description
✔ Base Fan: IEFB 330
✔ Airstream Material: Carbon Steel
✔ Wheel Material: Carbon Steel
✔ Motor (Premium Eff, 10hp, 1200rpm, 460V/60Hz/3ph, TEFC,
NEMA 256T)
✔ Paint (Color: TBD)
✔ Basic Fan (IEFB 330)
✔ Bolted Access Door (unless housing is too narrow)
✔ Drain with Plug (except alloys)
✔ Flanged & Drilled Inlet & Outlet
✔ Industrial Enamel Coating
✔ Ceramic Felt Shaft Seal (except arr 4)
Fan Data
Arrangement: 4V
Diameter: 33 in
Discharge: N/A
Rotation: CW
Class: 20
Max Design Temp: 150 °F
Max Temp Change Rate: 15 °F/min
Est. Ship Weight (per fan): 700 lb (base fan only)
