Description
Included Description:
Base Fan: BCNS 385 (402 housing)
Airstream Material: 2507 Super Duplex
Wheel Material: 2507 Super Duplex
Motor (Customer Supplied, 200hp, 3600rpm, 460V/60Hz/3ph,
TEFC, NEMA )
Flexible Coupling
OSHA Guards (Carbon Steel)
Non-std Shaft Seal (John Crane Double Mechanical 316 SS)
Housing Interior Continuous Welds (MIG)
Outlet Evase
316SS Shaft
ISPM15 Skid
Casing rated for 25 PSI (Bubble leak pressure test)
Bolted Access Door (unless housing is too narrow)
Drain with Plug
Flanged & Drilled Inlet & Outlet
Industrial Enamel Coating on CS parts, No Finish on SS parts
Add-ons and Options:
IE4 ABB Motor (Super Premium Eff, 200hp, 3600rpm, 460V/60Hz/3ph, TEFC, NEMA 447TS)
ATS MD2000 Ultimate multipoint auto luber
Fan bearing vibration sensors
Vibration Switch installed on pedestal
Forever Fan System (fan bearing vibration and temperature sensors with junction box and light)
ABB NEMA 12 VFD
